Mac Labeling System - Identify your glass before cutting

System for labels printing and apply on glass sheet.

As part of the ongoing search for innovative solutions aimed to improve the productivity and facilitate the management of glasses inside the glassware, Macotec recently introduced in the market "MACLABELING", the new system for printing and automatic application on the glass of labels for piece identify. This innovative system allows the automatic printing and application of labels on each piece present in the optimization, before the glass sheet scoring and breaking: in this way, after breaking, any single piece will be already identified with is proper label, greatly facilitating the work of the operators, which can comfortably read all the information needed for the management of the glass itself after the cutting process. Is also possible to print one or more barcodes for automatic detection of piece’s data by a code scanner. To be underline that the big sizes of the labels (maximum size 10 x 10 cm), allows to insert a big quantity of information: customer name, delivery date, piece size, eventual next working phase, glass sheet rack for storaging, company logo and everything customer consider usefull for pieces traceability inside the factory.

The printer is heat transfer type, that allows to use labels in plastic material water resistant. The application of the label is done “contact less” thanks to a air stream that “launch” the labels on the glass sheet which is pre-emptively cleaned from the dust. This solution avoid any contact between glass and mechanical parts, with the evident elimination of any risk of damaging the surface of the glass itself. All the parts used for this system are industrial type, that are designed to work in production hambient with an high work rate. The large diameter of the coil allows you to hold thousands of labels limiting downtime for loading.

MACLABELLING can be equipped on cutting table or line both for float and laminated glass.

Pablo Cattaneo
TAG: MacLabeling,Star Cut,Strato Advance XYZW,float glass, laminated glass
